LP Gear replacement for Pickering D750 stylus

LP Gear replacement for Pickering D750 stylus

Excellent special production D750 stylus for Pickering XV-15/750E cartridge
Made by Japanese shokunin seeking to create perfection with each stylus
Sound quality (SQ) and performance beyond current production substitutes
Diamond tip r/R radii: 8 × 18 µm (.0003 × .0007 inch)
Thin-wall alloy tube cantilever for groove tracing accuracy and fidelity
Each stylus undergoes QC and listening test as final inspection
LP GEAR® stylus - Above and beyond copies and generics


LP Gear replacement for Pickering D750 stylus

Code: PICSD0750

Upgrade stylus: See Related Products.
Product Info


The LP Gear replacement for the Pickering D-750 D750 needle stylus features a highly polished special elliptical diamond for superior tracing of record grooves. It results in accurate detail and clarity of voice, music and harmonics.

Upgrade Options
- For upgrade stylus and accessories that enhance sound quality and fidelity, refer to Related Products.

Pickering XV-15/750E Cartridge Specifications
- Type: Moving Iron
- Frequency response: 10-25,000 Hz
- Output voltage: 4.4 mV
- Channel separation: 35 dB
- Tracking force: 1.00 ± ½ g
- Mounting: Standard 12.7 mm (½ inch) mounting centers
- Stylus color: Black with gold ellipse
- Stylus radius: Stylus radius: .0003 × .0007
- Replacement stylus: D750

Notes: (1) Tracking force greater than the maximum indicated should not be used.
(2) Specifications for original Pickering cartridge provided for reference only.
