Contact Us LP Gear S70SR stylus for Excel ES-70S cartridge
EXCELES70S
● Finest quality S70SR stylus for Excel ES-70S cartridge
● Very clean tone, polished smoothness and wide frequency range
● Made in Japan to reproduce with highest fidelity and sound quality
● Special conical diamond tip radius: 15 µm (.0006 inch)
● Low-mass alloy cantilever for tracing accuracy and fidelity
● Each stylus undergoes QC and listening test as final inspection
● LP GEAR® stylus - Above and beyond copies and generics
- Product Info
S70SR STYLUS FOR EXCEL ES70S ES-70S CARTRIDGE
The LP Gear S70SR stylus for the Excel ES-70S ES70S phono cartridge features a 0.6 mil conical diamond for long playing life and extraordinary rendition of voice and music.
Excel ES-70S Cartridge Specifications
- Type: Moving Magnet
- Frequency range: 15-25,000 Hz
- Output voltage @ 1kHz: 5.0 mV
- Channel balance @ 1kHz: <1.5dB
- Channel separation @ 1kHz: 20dB
- Dynamic compliance (100Hz): 10 × 10-6 cm/dyne
- Cantilever: Special type aluminum pipe
- Stylus type: Conical
- Stylus tip radius: 0.6 mil diamond
- Tracking force: 1.0 - 2.5 g
- Recommended load resistance: 47 kOhm
- Cartridge color, body/stylus: Black/Silver/Blue
- Weight: 5.0 g
- Stylus replacement: S70SR stylusNote: Original cartridge specification provided for reference only.
