REPLACEMENT FOR EMPIRE S44E STYLUS
- LP GEAR® stylus - Above and beyond copies and generics
The LP Gear replacement for the Empire S 44 E stylus
features a highly polished special elliptical diamond
with .0003 x .0007 inch radii bonded to a thin-wall
aluminum alloy cantilever. Its excellent tracing of record
grooves results in very fine detail, clarity and harmonically
excellent sound quality. The color of the stylus may vary.
- For upgrades and accessories that enhance sound quality and fidelity, refer to Related Products.
Empire TC 40 Cartridge Specifications
- Frequency response: 7-30,000 Hz
- Tracking force: 0.75-2.0 g
- Channel separation @ 1kHz / 1kHz: 28 / 20 dB
- Stylus size & shape: .2 × .7 mil Elliptical
- Cantilever: Tapered aluminum alloy
- Vertical tracking angle: 20°
- Load resistance: 47 kΩ
- Capacitance: 300 pf
- Output voltage @ 3.5cm/sec: 3.5 mV
-Stylus replacement & color: S44E green
Note: Specifications provided for reference to the original product only.
