LP Gear SAM10 stylus for Signet AM-10s AM10s cartridge

LP Gear SAM10 stylus for Signet AM-10s AM10s cartridge

Special elliptical diamond LPGEAR SAM10 stylus for very high fidelity
.0003 x .0007 inch radii for precision tracing accuracy
Precision engineered and exquisitely crafted in Japan
Genuine, 100% authentic Audio-Technica stylus


LP Gear SAM10 stylus for Signet AM-10s AM10s cartridge

Code: SIGAM10s

Upgrade Stylus: See Related Products.
Product Info


The LP Gear SAM10 stylus equivalent for the Signet Analog Master Series AM-10s AM10s cartridge is the Audio-Technica ATN100E stylus. It features a aluminum alloy tube cantilever and a highly polished special elliptical diamond for superb tracking and tracing of record grooves. It results in finer detail and harmonically complete sound quality.

Signet AM10s Cartridge Specifications
- Mounting: ½ centers
- Type: Moving Magnet, Twin Flux UniCore
- Output voltage: 5.0 mV @ 5cm/sec
- Frequency response: 15-25,000 Hz
- Channel Balance: 1.5 dB
- Channel separation at 1kHz | 10kHz : 27 dB | 17 dB
- Load impedance: 47,000 Ohms
- Recommended load capacitance: 100-200 pF
- Inductance: 490 mH
- DC resistance: 780 Ohms
- Stylus type: 0.3 x 0.7 mil elliptical, round shank mounted
- Stylus cantilever: Thin-wall alloy tube
- Vertical tracking angle: 20°
- Stylus replacement: User replaceable, SAM10 stylus
- Tracking force: 1.3 - 2.3 g
- Weight: 6.2 g

Note: Provided for reference only. Specifications are subject to change without notice.

Upgrade Options
- For High grade upgrade stylus and essentials that enhance sound quality and fidelity, refer to Related Products.
