MUSIC HALL MAGIC-2 CARTRIDGE

The Music Hall Magic 2 cartridge features excellence right out of the box. Made for Music Hall by Ortofon, it offers a naturally refined tonal balance with vivid and graceful detail - music you can listen to for hours and hours. That's the Magic 2 for you!

Magic 2 Cartridge Details
- Tonearm mount: 1/2 inch
- Type: Moving magnet
- Output: 4mV
- Frequency range: 20-22,000 Hz
- Frequency response: 20-18,000 Hz +2/-3 dB
- Compliance, dynamic, lateral: 20 µm/mN
- Stylus type: Elliptical
- Stylus tip radius: r/R 8/18 µm (.0003 x .0009 inch)
- Tracking force range: 1.5-2.0 g (15-20 mN)
- Tracking force, recommended 1.75 g (1.75 mN)
- Tracking angle: 20°
- Internal impedance, DC resistance: 750 Ohm
- Internal inductance: 450 mH
- Recommended load resistance: 47 kOhm
- Recommended load capacitance: 200-600 pF
- Body color: Blue
- Cartridge weight: 5g
