VMN40ML
● Genuine Audio-Technica stylus For VM740ML, VM540ML, 2.2 x 12 mil.
● Nude Microline (2.2 × 0.12 mil)
● Exquisitely crafted and precision engineered in Japan
● Finest quality available by the original manufacturer
● Curated by LP GEAR® for long-term listening pleasure
- Product Info
AUDIO-TECHNICA VMN40ML STYLUS
The Audio-Technica VMN40ML is the stylus replacement specified for the VM540ML cartridge.
Audio-Technica VMN40ML stylus specifications
- Type: VM
- Frequency response: 20 ~ 27,000 Hz
- Output voltage: 4.0 mV (1kHz, 5 cm/sec.)
- Channel separation: 30 dB (1kHz)
- Output balance: 1.0 dB (1kHz)
- Tracking force: 1.8 ~ 2.2 g (2.0 g standard)
- Static compliance: 40 × 10-6 cm/dyne
- Dynamic compliance: 10 × 10-6 cm/dyne (100Hz)
- Stylus: Nude Microline (2.2 × 0.12 mil)
- Cantilever: Aluminum tapered pipe
- Vertical tracking angle: 23 °
Note: Specifications are subject to change without notice.
