LP Gear Ultimate Ortofon 2M Blue Cartridge SET

OR2MBLUEHDH
$278.98
LP Gear Ultimate Ortofon 2M Blue Cartridge SET


LP GEAR® Ultimate ½ inch mount headshell
Highly precision processed 2.5 mm high rigidity Duralumin
SOAR HD5 headshell wires for exceptional sound quality
Aligned length ∼52 mm for use with many tonearms
Alignment adjustable for extra precision and compatibility
Free alignment protractor
16.7g weight with mounted Ortofon 2M Blue cartridge

Processing...

LP Gear Ultimate Ortofon 2M Blue Cartridge SET

Code: OR2MBLUEHDH
$278.98

LP Gear Ultimate Ortofon 2M Blue Cartridge SET is currently unavailable.
Enter your email here to be notified when it is available
Product Info

LP GEAR ULTIMATE ORTOFON 2M BLUE CARTRIDGE SET
- Ortofon 2M Blue cartridge premounted on world-class LP GEAR Ultimate Headshell

The LP Gear premounted Ortofon 2M Blue cartridge with Ultimate (U) Headshell offers superior sonic capability and compatibility with turntables:
- LP GEAR® Ultimate High-Definition half-inch mount headshell
- Highly precision processed 2.5 mm high rigidity Duralumin
- SOAR HD5 headshell wires for exceptional sound quality
- Aligned length ∼52 mm for use with many tonearms
- Alignment adjustable for extra precision and compatibility
- Free alignment protractor
- Total weight of 16.7g with Ortofon 2M Blue cartridge is suited to more turntables and their tonearms. There is no need to change the counterweight.

Ortofon 2M Blue Phono Cartridge Specifications
- Output voltage @ 1kHz: 5.5mV
- Channel balance @ 1kHz: 1.5dB
- Channel separation: 25dB @ 1kHz; 15dB @ 15kHz
- Frequency range: 20Hz-25kHz
- Frequency response: 20Hz-20kHz +2/-1dB
- Tracking ability @ 315Hz @ recommended tracking force: 80 µm
- Compliance dynamic lateral: 20 µm/mN
- Stylus type: Nude elliptical
- Stylus tip radius: .0003 x .0007 inch
- Tracking force: 1.6 - 2.0 g
- Recommended tracking force: 1.8 g (18 mN)
- Tracking angle: 20°
- Internal impedance DC resistance: 1.3k ohms
- Internal inductance: 700 mH
- Recommended load resistance: 47k ohms
- Recommended load capacitance: 150 - 300 pF
- Color: Black/Blue
- Weight: 7.2 g
- Stylus replacement: Ortofon 2M Blue

Upgrade Options
- For upgrades and accessories that enhance sound quality and fidelity, refer to Related Products.
