LP Gear T4P REFERENCE SERIES VL phono cartridge

LP Gear T4P REFERENCE SERIES VL phono cartridge

"Easily matches my (Ortofon) OM-30, but with more body. The data retrieval is stunning for such a cheap cartridge. You can easily embarrass your friends Ortofon Reds and Grado Greens with this cartridge."

"Stylus shape is king and this needle will get deeper into the groove than any standard elliptical and will play the undamaged part of the record that previously poorly set up conical and ellipticals have damaged."


LP Gear T4P REFERENCE SERIES VL phono cartridge


Product Info


LP Gear introduces the T4P Reference Series VL phono cartridge for those seeking reference quality discernment and core competency in a P-mount phono cartridge.

By preference and conviction the LP Gear T4P Series of cartridges offer world-class craftsmanship, excellent performance, exemplary value, natural and clean tone and musicality in a simple extraordinary package. They are fitted for P-mount or T4P tonearms. Each is crafted with tolerances held to mere thousandths of an inch. Stringent quality control assures that tolerances and performance criteria are maintained for each product. As in other series within the LP Gear magnetic phono cartridge range, your investment in a cartridge does not become obsolete. When your appreciation of music and critical listening develop and your demands for sophisticated electronics grow, you can easily and sensibly upgrade performance by installing a better stylus within the series.

The LP Gear T4P Reference Series VL offers elevated and very high accuracy and musicality. It uses a Vivid-Line diamond, exquisitely polished with precision, and then carefully mounted on a thin metal alloy tubular cantilever for long playing life and exceptional tracing of record grooves. A Vivid-Line diamond is exceptional in its tracing capability and is thus used in high fidelity listening and recording where the mission is to listen to and enjoy digitized music as you would the original recording.

The result exceptional fidelity and faithfulness to the original recording. We believe it is a world-class performer and one of the finest P-mount cartridge crafted today.

LP Gear T4P Reference Series VL Phono Cartridge Specifications
- Frequency response: 12Hz-28kHz
- Output voltage @ 1kHz, 5 cm/sec: 3mV
- Channel separation @ 1kHz/10kHz: 29/18dB
- Vertical tracking force: 1.0-1.5 g
- Stylus shape: Vivid Line diamond
- Stylus radius: .0029 x .0002 inch
- Cantilever: Thin-wall alloy tube
- Recommended load impedance: 47k ohms
- Recommended load capacitance: 100-200 pf
- Weight: 6 g
- Dimensions (mm): 34l x 10w x 17h
- Stylus replacement: LP Gear ATNSERIESVL
- Stylus upgrade: LP Gear ATNSERIESVS
