AUDIO-TECHNICA AT-440MLB AT 440MLB AT440MLB PHONO CARTRIDGE
- With improvements in stylus damper and contacts

With its improved stylus mechanicals, advanced generator, and Microline stylus, the latest model of this highly regarded and multi-awarded moving magnet cartridge continues to offer top performance.

AT440MLa and AT440MLb Comparison
In initial listening sessions, there are minor though distinguishable sonic differences. The AT440MLb is crispier and has more high frequency energy. You will hear more nuanced detail and clarity. It will be exquisite in audio systems that need a tad of luster. In contrast, the AT440MLa offers a relatively smoother top end, harmonic rhythm and melodic bass.

Audio-Technica AT440MLb Phono Cartridge Specifications
- Output voltage @ 1kHz,5cm/sec.: 4mV
- Channel balance @ 1kHz: 1.0dB
- Channel separation @ 1kHz: 28dB
- Frequency response: 20Hz-25kHz
- Dynamic compliance (x10-6 cm/dyne): 10
- Static compliance (x10-6 cm/dyne): 40
- Stylus type: 0.12 mil nude square micro-linear
- Cantilever: Aluminum tube
- Tracking force range: 1.0 - 1.8 g
- Tracking force recommended: 1.4 g (14 mN)
- Vertical tracking angle: 20°
- Coil impedance @ 1kHz: 3.2k ohm
- Coil inductance @ 1kHz: 490 mH
- Load Capacitance: 100 - 200 pF
- Recommended load resistance: 47k ohms
- Color: Black/Violet
- Weight: 6.5 g
- Dimensions (mm): H17.3 × W16 × D28.2
- Stylus replacement: Audio-Technica ATN440MLb
- Accessories included: Non-magnetic screw driver driver × 1, cartridge mounting screws 5mm × 2,10mm × 2, Washer × 4, nut × 2, hexagonal nut × 2, brush × 1, PCOCC lead set × 1.
