Ortofon MC-1 Turbo phono cartridge

ORMC0001 Not Yet Rated | Write the First Review
$189.00
Ortofon MC-1 Turbo phono cartridge


MC High Output with 3.3 mV at 1kHz, 5 cm.sec
Phono MM connection, no transformer or head amp needed
Diamond tip r/R radii: 8/18 µm (.0003 × .0007 inch)
Tracking force: 1.8 - 2.2g
Frequency range: 20-25,000 Hz

Processing...

Ortofon MC-1 Turbo phono cartridge

Code: ORMC0001 Not Yet Rated | Write the First Review
$189.00

Ortofon MC-1 Turbo phono cartridge is currently unavailable.
Enter your email here to be notified when it is available
Product Info

ORTOFON MC-1 MC 1 MC1 TURBO PHONO CARTRIDGE 3.3 mV

Many audiophiles consider moving coil (MC) cartridges as the best way to play LPs. The Ortofon MC1 MC 1 MC-1 Turbo offers the legacy Ortofon high quality sound in a high output package hence the nomenclature "Turbo". It produces a 3.3 mV output and has a recommended load impedance of 47K like a standard moving magnet (MM) cartridge hence it can be directly connected to a MM phono preamp.

Its quality of construction is first rate. Musically the Ortofon MC-1 Turbo offers a smooth and refined sound with good bass control. Its elliptical stylus tracks very well and eloquently extracts groove information.

Ortofon MC-1 Turbo Phono Cartridge Specifications
- Output voltage at 1000 Hz, 5cm/sec.: 3.3 mV
- Channel balance at 1 kHz: < 2 dB
- Channel separation at 1 kHz / 15 kHz: > 22 / 15 dB
- Frequency range at - 3dB: 20 - 25,000 Hz
- Frequency response: 20-20.000 Hz + 4 / - 1 dB
- Tracking ability: > 65 µm
- Compliance, dynamic, lateral: 13 µm/mN
- Stylus type: .0003 x .0007 inch Special elliptical diamond
- Equivalent stylus tip mass: 0.75 mg
- Tracking force range: 1.8 - 2.2 g (18-22 mN)
- Tracking force, recommended: 2.0 g (20 mN)
- Tracking angle: 20°
- Internal impedance, DC resistance: 100 Ohm
- Recommended load impedance: 47 kOhm
- Cartridge color: Black
- Cartridge body material: Noryl
- Cartridge weight: 4.1 g
