Music Hall MMF-1.3 turntable

MMF13
$299.00
Music Hall MMF-1.3 turntable


Belt drive 3 speed: 33.3, 45, 78 RPM
Electronic speed-controlled motor
Aluminum tonearm with removable headshell
Built-in phono pre-amp
Piano black MDF plinth and vibration-damping rubber platter mat
Complete plug-and-play package with Audio-Technica AT-3600 cartridge

Processing...

Music Hall MMF-1.3 turntable

Code: MMF13
$299.00

Product Info

MUSIC HALL MMF-1.3 TURNTABLE
- Complete, 3-speed audiophile-capable plug-and-play package for easy record playing and long-term vinyl listening enjoyment

The unrivalled Music Hall MMF 1.3 lets you play all of your records beautifully and sets a new benchmark in plug-and-play turntables. The construction of the MMF1.3 has been simplifued to focus on the critical components: the bearing, motor and tonearm.

Feature List
Belt drive
Three-speed manual operation: 33-1/3, 45 RPM and 78 rpm1
Electronic speed controlled motor
Precision aluminum alloy straight tonearm
Removable half-inch mount headshell for easy cartridge changing
Piano black MDF plinth
Audio-Technica AT3600L cartridge comes pre-mounted and precision-aligned
Vibration damping feet
High quality gold RCA connectors with detachable phono cable included
Aluminum platter and special vibration damping platter mat
Dust cover and 45 rpm adaptor
Built-in phono pre-amp
Quick and easy to assemble, even easier than you might think.

____________________________________

Footnote 1: 78 RPM record playing requires a 78RPM stylus. See Related Products below.

Specifications
Music Hall MMF-1.3 Technical Specifications

General Section
- Power supply: DC12V, 2.0A universal power supply
- Consumption: 4W
- Dimensions: 17.1(W) x 14.5(D) x 4.2(H) in. | 435(W) x 367(D) x 106(H) mm
- Weight: 11 lbs | 5.0 Kg

Turntable Section
- Type: 3-speed full manual
- Motor: DC motor
- Driving method: Belt drive
- Turntable platter: 296mm dia. aluminum die-cast
- Speeds: 33 1/3, 45, and 78rpm
- Wow and flutter: Typical - less than 0.1% WTD at 3KHz RMS(CD-4005)
Limit: Less than 0.15% WTD at 3KHz RMS(CD-4005)
- S/N ratio: Typical - More than 62dB (DIN-B) (SS-4242)
Limit: More than 62dB (DIN-B) (SS-4242)
- Speed tolerance: 3000Hz +/-1%(CD-4005)

Cartridge Section
- Type: Moving Magnet cartridge
- Stylus: Diamond stylus
- Channel separation: > 15 dB at 1KHz (CD-4005)
- Channel balance: Within 2.5 dB at 1KHz (CD-4005)
- Phono output level: 1.5 ~ 3.6 mV at 1KHz 5cm/sec (CD-4005)
- Line output: 90-216 mV at 1KHz 5cm/sec (CD-4005)
- RIAA: 20Hz ~ 20KHz +1/-3 dB

Cartridge
- Cartridge: AT3600L
- Output voltage: 2.5mV +/- 3dB at 1KHz 3.54cm/sec (AT6606A)
- Channel separation measurement point 1KHz: over 18dB (AT6606A)
- Channel balance: within 2dB or less at 1KHz (AT6606A)
- Frequency response: 0 +/-3dB at 10KHz (AT6606A)(Value at 10KHz based on value at 1KHz)
- Tracking force: 3.5 +/- 0.5 grams

Tonearm Section
- Type: Dynamic balanced straight shaped w/soft damping control
- Effective arm length: 221.5 mm
- Overhang: 19 mm
- Offset angle: 25.61 degrees
- Tracking error angle: 3 degrees or less
- Stylus pressure adjustment method rotation movability
- Arm lifter: Oil damper type
