VM540ML Audio-Technica cartridge replacement for AT440MLa cartridge

ATC05
$279.00
VM540ML Audio-Technica cartridge replacement for AT440MLa cartridge


AT440ML's Provenance of excellence ~ 2013, 2014, 2015, 2016, 2017, 2018 Editors Choice Award The Absolute Sound

"Brim with opulent timbres and resounding tunefulness."1

"This is one of the great audio bargains...it is closer to the master tape."2

"The AT440MLa has provided me with more hours of vinyl enjoyment than any other."3

Processing...

VM540ML Audio-Technica cartridge replacement for AT440MLa cartridge

Code: ATC05
Retail: $390.00.
$279.00




Product Info

VM540ML AUDIO-TECHNICA CREPLACEMENT FOR AUDIO-TECHNICA (AT-440MLA AT 440MLA) AT440MLA CARTRIDGE
- AT440's Provenance of Excellence: 2013, 2014, 2015, 2016, 2017, 2018 Editors Choice Award The Absolute Sound March Issue 231, 241, 251, 261, 271, 281.

With the formidable VM540ML phono cartridge, Audio-Technica has replaced and superseded—at a more affordable price—the highly regarded AT440's (retail: $390.00) musical excellence that rightfully should be compared with moving magnets costing up to $500. Yes, it is that good. The Audio-Technica VM5440ML's excellence lies in the suitable employment of advanced designs uniquely available to Audio-Technica because of its rich technical history and production capabilities:

Audio-Technica's Vector-Aligned Dual Magnet design, which uses two tiny magnets to achieve ideal geometry and low magnet mass, for excellent channel separation and extended frequency response.

The Audio-Technica VMN40ML's MicroLine stylus produces more accurately rendered high frequency response with less wear and distortion than elliptical or conventional linear contact styli. The small curving rate of the MicroLine stylus enables it to track and playback the inner part of the record groove that other styli can hardly maintain. Also the curving rate of the MicroLine stylus does not change until the stylus is almost worn unlike that of conventional styli which increases as they are used. Accordingly, the MicroLine stylus has a much longer average playing life. It plays better, longer.

Audio-Technica AT440MLa Phono Cartridge Specifications
- Output voltage @ 1kHz,5cm/sec.: 4mV
- Dynamic compliance (x10-6 cm/dyne): 10
- Static compliance (x10-6 cm/dyne): 40
- Stylus type: 0.12 mil nude square micro-linear
- Tracking force range: 1.0 - 1.8 g
- Tracking force recommended: 1.4 g (14 mN)
- Vertical tracking angle: 20°
- Coil impedance @ 1kHz: 3.2k ohm
- Coil inductance @ 1kHz: 490 mH
- Recommended load resistance: 47k ohms
- Color: Black/Violet
- Weight: 6.5 g
- Dimensions (mm): H17.3 × W16 × D28.2
- Stylus replacement: Audio-Technica ATN440MLA
- Accessories included: Screwdriver, screws, nuts, headshell wires

Audio-Technica VM540ML cartridge specifications
- Type: VM
- Frequency response: 20 ~ 27,000 Hz
- Output voltage: 4.0 mV (1kHz, 5 cm/sec.)
- Channel separation: 30 dB (1kHz)
- Output balance: 1.0 dB (1kHz)
- Tracking force: 1.8 ~ 2.2 g (2.0 g standard)
- Coil impedance: 2.7 kΩ (1kHz)
- DC resistance: 800 Ω
- Load impedance: 47 kΩ
- Load capacitance: 100 ~ 200 pF
- Coil inductance: 460 mH (1kHz)
- Static compliance: 40 × 10-6 cm/dyne
- Dynamic compliance: 10 × 10-6 cm/dyne (100Hz)
- Stylus: Nude Microline (2.2 × 0.12 mil)
- Cantilever: Aluminum tapered pipe
- Vertical tracking angle: 23 °
- Dimensions: 17.3(H) × 17.0(W) × 28.2(D) mm
- Weight: 6.4 g
- Replacment stylus: VMN40ML
- Accessories: Cartridge installtion screws 5mm × 2, 10 mm × 2, Washer × 2, Hexagon nut × 2, Non-magnetic screwdriver × 1, Brush × 1, Lead wire set × 1

Note: Specifications are subject to change without notice.

______________________________________ _
Footnote 1: Neil Gader, The Absolute Sound 2015 Editors Choice Awards: Audio-Technica AT440MLa / AT150MLX (March 2015, Issue 251), 104. This is a summary of a full review from Issue 216 that describes these cartridges as offering their own authenticity and musical rewards over the long haul.
Footnote 2: David A. Rich, The Sensible Sound, Issue 112, May/June 2007
Footnote 3: Alberto De Roma, Audio VeeViews

Specifications
Audio-Technica AT440MLa Phono Cartridge Specifications
- Output voltage @ 1kHz,5cm/sec.: 4mV
- Channel balance @ 1kHz: 0.8dB
- Channel separation @ 1kHz: 27dB
- Frequency response: 20Hz-20kHz
- Dynamic compliance (x10-6 cm/dyne): 10
- Static compliance (x10-6 cm/dyne): 40
- Stylus type: 0.12 mil nude square micro-linear
- Tracking force range: 1.0 - 1.8 g
- Tracking force recommended: 1.4 g (14 mN)
- Vertical tracking angle: 20°
- Coil impedance @ 1kHz: 3.2k ohm
- Coil inductance @ 1kHz: 490 mH
- Recommended load resistance: 47k ohms
- Color: Black/Violet
- Weight: 6.5 g
- Dimensions (mm): H17.3 × W16 × D28.2
- Stylus replacement: Audio-Technica ATN440MLA
- Accessories included: Screwdriver, screws, nuts, headshell wires

Audio-Technica VM540ML cartridge specifications
- Type: VM
- Frequency response: 20 ~ 27,000 Hz
- Output voltage: 4.0 mV (1kHz, 5 cm/sec.)
- Channel separation: 30 dB (1kHz)
- Output balance: 1.0 dB (1kHz)
- Tracking force: 1.8 ~ 2.2 g (2.0 g standard)
- Coil impedance: 2.7 kΩ (1kHz)
- DC resistance: 800 Ω
- Load impedance: 47 kΩ
- Load capacitance: 100 ~ 200 pF
- Coil inductance: 460 mH (1kHz)
- Static compliance: 40 × 10-6 cm/dyne
- Dynamic compliance: 10 × 10-6 cm/dyne (100Hz)
- Stylus: Nude Microline (2.2 × 0.12 mil)
- Cantilever: Aluminum tapered pipe
- Vertical tracking angle: 23 °
- Dimensions: 17.3(H) × 17.0(W) × 28.2(D) mm
- Weight: 6.4 g
- Replacment stylus: VMN40ML
- Accessories: Cartridge installtion screws 5mm × 2, 10 mm × 2, Washer × 2, Hexagon nut × 2, Non-magnetic screwdriver × 1, Brush × 1, Lead wire set × 1
