Grado Green3 P-mount T4P cartridge - For US sale only

GRADGRNT4P
$125.00
Grado Green3 P-mount T4P cartridge - For US sale only
Processing...

Grado Green3 P-mount T4P cartridge - For US sale only

Code: GRADGRNT4P
$125.00




Product Info

GRADO GREEN 3 GREEN3 PHONO CARTRIDGE - P-MOUNT T4P

Grado P-mount T4P cartridges are acclaimed worldwide by experts as virtually the finest pickups at their price points. The Grado Prestige series of P-mount T4P cartridges are designed for high output and excellent stability under the most demanding conditions. All of the range uses Grado's patented Optimized Transmission Line (OTL) technology which makes your records sound quieter, improve the height, width and depth of the sound stage and offer more detail than previously achievable. Grado's OTL technology is all about delivering more music, more performance.

the Green3 uses a three-piece OTL cantilever that has a Grado specific diamond mounted on a brass bushing. The Green3 are hand selected from Black3 production runs which meet higher test specifications. Approximately 15% of the run usually exhibits these specs and become a Green3.

Grado’s optimized transmission line (OTL) technology provides an ideal transfer of signal from the surface of the LP to the generator of the system. This technology rejects unwanted resonances and lowers distortion preserving the fundamental and harmonic frequencies of the music. This also helps keep noise generated by the motor system in the cartridge to a minimum.

Grado’s OTL stylus/cantilever design makes records sound quieter, improves the height, width, and depth of the soundstage, and present more detail than previously obtainable.

The Green3 are all hand assembled by Grado artisans in Brooklyn, with some artisans having over 25 years of experience. With the recent development of the highly received Lineage Series of cartridges, Gardo was able to harness trickle down of technology and bring a new technique to the Green3. This updated series of cartridges offers excellent tonal balance, dynamics, and realism, for a most rewarding reproduction of vocals and instruments. Gardo's coil winding techniques, using ultra high purity copper wire which were honed during the development of the Lineage Series, have let the electrical circuits achieve unison between the four coils in each phono cartridge. This allows for a precise balance between channels and accurate stereo imaging.

As in all Grado phono cartridges the Green3 is powered by a twin magnet system that optimizes the balance between stereo channels. All internal magnetic circuit parts are held to extremely high tolerances creating the desired stereo imaging. Grado’s patented Flux-Bridger design allows the Green3 to have one of the lowest effective moving mass generating systems while creating an excellent balance throughout the full frequency range.

The development of the Epoch in the Lineage Series enabled Grado to gain in-depth experience with using an outer housing as a damping device. This led to the creation of a process which de-stresses the chassis and dissipates unwanted energy & resonant frequencies, allowing the desired signal to travel with purity.

Grado Green3 (Green 3) Phono Cartridge Specifications
- Frequency Response: 10-55,000 Hz
- Principal: MI
- Channel Separation at 1KHz: 30
- Input Load: 47K
- Output at 1KHz 5CM/sec.: 5mV
- Recommended Tracking Force: 1.5
- Stylus Type: E
- Inductance: 45mH
- Resistance: 475
- Compliance CUs: 20
- Stylus Replacement: User replaceable
- Mounting: Half-inch standard Weight: 5.5 g

Stylus Replacements
- Standard stylus: Grado Green Stylus
- Upgrade stylus: Grado 8MZ Stylus
